Laravel Reverb WebSocket Broadcasting: Real-Time Channels, Auth, and Scaling Patterns

Beyond the Hello-World: Laravel Reverb in Production

Laravel Reverb ships as a first-party WebSocket server, but most tutorials stop at php artisan reverb:start and a public channel. Real applications need private channels with proper authorization, presence channels for collaborative UIs, and a deployment story that survives more than one server.

Channel Types and When to Use Each

| Channel | Auth required | Presence data | Typical use | |---------|--------------|---------------|-------------| | Public | No | No | Public feeds, announcements | | Private | Yes | No | Per-user notifications, order updates | | Presence| Yes | Yes | Collaborative editors, live cursors |

Defining Private and Presence Channels

Channel routes live in routes/channels.php. Return true/false for private channels; return an array of user metadata for presence channels — Reverb forwards that payload to every subscriber.

// routes/channels.php

use App\Models\Project;
use Illuminate\Support\Facades\Broadcast;

// Private: only the owning user may subscribe
Broadcast::channel('orders.{orderId}', function ($user, int $orderId) {
    return $user->orders()->where('id', $orderId)->exists();
});

// Presence: return metadata so the UI knows who is online
Broadcast::channel('projects.{projectId}', function ($user, int $projectId) {
    $project = Project::find($projectId);

    if (! $project?->members()->where('user_id', $user->id)->exists()) {
        return false;
    }

    return [
        'id'     => $user->id,
        'name'   => $user->name,
        'avatar' => $user->avatar_url,
    ];
});

Broadcasting an Event on a Presence Channel

// app/Events/CursorMoved.php

use Illuminate\Broadcasting\PresenceChannel;
use Illuminate\Contracts\Broadcasting\ShouldBroadcast;

class CursorMoved implements ShouldBroadcast
{
    public function __construct(
        public readonly int   $projectId,
        public readonly int   $userId,
        public readonly float $x,
        public readonly float $y,
    ) {}

    public function broadcastOn(): array
    {
        return [new PresenceChannel("projects.{$this->projectId}")];
    }

    // Only broadcast the payload the client actually needs
    public function broadcastWith(): array
    {
        return ['user_id' => $this->userId, 'x' => $this->x, 'y' => $this->y];
    }

    // Throttle: drop duplicate events within the same second
    public function broadcastWhen(): bool
    {
        return true; // add cache-based throttle here if needed
    }
}

Tuning the Reverb Server

Reverb's config lives in config/reverb.php. The most impactful knobs for production:

'servers' => [
    'reverb' => [
        'host'    => env('REVERB_SERVER_HOST', '0.0.0.0'),
        'port'    => env('REVERB_SERVER_PORT', 8080),
        'options' => [
            // Raise open-file limits before touching this
            'max_connections'  => 10_000,
            // Keep idle connections alive; lower = faster cleanup
            'max_request_size' => 10_000, // bytes
        ],
    ],
],

Pair this with a systemd unit that sets LimitNOFILE=65535 so the OS doesn't cap you first.

Horizontal Scaling with Redis Pub/Sub

A single Reverb process is a single point of failure. Run multiple workers behind a load balancer and let Redis fan out messages between them:

// config/reverb.php  (scaling section)
'scaling' => [
    'enabled' => true,
    'driver'  => 'redis',
    'connection' => env('REVERB_SCALING_CONNECTION', 'default'),
],

Each Reverb worker subscribes to the same Redis channel. When worker A receives a broadcast, Redis delivers it to workers B and C so their connected clients all receive the event — no sticky sessions required.

Tip: Use a dedicated Redis connection for Reverb scaling, separate from your cache and queue connections, to avoid head-of-line blocking under load.

Client-Side Authentication Flow

Echo's auth endpoint hits /broadcasting/auth by default. Ensure your API middleware group includes auth:sanctum (or your guard of choice) and that CORS allows the origin your frontend runs on:

import Echo from 'laravel-echo';
import Pusher from 'pusher-js';

window.Echo = new Echo({
    broadcaster: 'reverb',
    key: import.meta.env.VITE_REVERB_APP_KEY,
    wsHost: import.meta.env.VITE_REVERB_HOST,
    wsPort: import.meta.env.VITE_REVERB_PORT,
    forceTLS: false,
    enabledTransports: ['ws'],
    authEndpoint: '/broadcasting/auth',
});

window.Echo
    .join(`projects.${projectId}`)
    .here(members  => console.log('online:', members))
    .joining(member => console.log('joined:', member))
    .leaving(member => console.log('left:',   member))
    .listen('CursorMoved', e => moveCursor(e));

Key Takeaways

• Private channels return a boolean; presence channels return a metadata array — both go through routes/channels.php.
• Keep broadcastWith() lean; every connected client receives the full payload.
• Enable Redis scaling before you need it — retrofitting under load is painful.
• Separate the Reverb Redis connection from cache/queue to prevent contention.
• Set OS-level file descriptor limits (LimitNOFILE) before raising max_connections.
