Filament v4 Schema-Based Forms: Unified Schema API and Infolist Patterns

Filament v4 Schema-Based Forms and Infolists

Filament v4 introduced one of its most architecturally significant changes: a unified Schema API that collapses the previously separate form and infolist definition surfaces into a single, composable layer. If you have built Filament v3 resources, you know the friction — form(Form $form) and infolist(Infolist $infolist) each demanded their own component trees, leading to duplicated field definitions for read and write views.

Filament v4 solves this by making Schema the first-class citizen.

The Old Friction

In v3, a TextInput in a form and a TextEntry in an infolist were entirely separate classes with separate APIs. Keeping them in sync was a maintenance burden:

// v3 — two separate definitions, easy to drift
public static function form(Form $form): Form
{
    return $form->schema([
        TextInput::make('email')->email()->required(),
    ]);
}

public static function infolist(Infolist $infolist): Infolist
{
    return $infolist->schema([
        TextEntry::make('email'),
    ]);
}

The v4 Unified Schema

Filament v4 introduces Schema components that are context-aware: the same component tree renders as editable inputs inside a form context and as read-only entries inside an infolist context. You define the schema once and let Filament resolve the correct renderer.

use Filament\Schema\Schema;
use Filament\Schema\Components\TextInput;
use Filament\Schema\Components\Section;

public static function schema(Schema $schema): Schema
{
    return $schema->components([
        Section::make('Identity')
            ->schema([
                TextInput::make('name')
                    ->required()
                    ->maxLength(120),

                TextInput::make('email')
                    ->email()
                    ->required(),
            ]),
    ]);
}

Both the EditRecord and ViewRecord pages consume this single schema() method. The framework injects the correct context — form or infolist — at render time.

Reusable Schema Components

The real power emerges when you extract schemas into dedicated classes. This is the pattern I reach for on any resource with more than a handful of fields:

namespace App\Filament\Schemas;

use Filament\Schema\Schema;
use Filament\Schema\Components\TextInput;
use Filament\Schema\Components\Select;

class UserIdentitySchema
{
    public static function make(): array
    {
        return [
            TextInput::make('name')->required(),
            TextInput::make('email')->email()->required(),
            Select::make('role')
                ->options(Role::class)
                ->required(),
        ];
    }
}

Then compose it anywhere:

public static function schema(Schema $schema): Schema
{
    return $schema->components([
        ...UserIdentitySchema::make(),
        ...BillingAddressSchema::make(),
    ]);
}

This is clean, testable, and trivially shareable across resources, modals, and wizard steps.

Conditional Visibility

Conditional logic works identically whether the schema is rendered as a form or infolist:

TextInput::make('vat_number')
    ->visible(fn (Get $get): bool => $get('is_business') === true)
    ->required(fn (Get $get): bool => $get('is_business') === true),

The Get closure resolves live state in form context and static record state in infolist context — no branching required in your schema definition.

Practical Migration Note

If you are migrating from v3, the key shift is:

1. Replace form() + infolist() with a single schema() method.
2. Swap TextEntry, ImageEntry, etc. for their unified Schema\Components equivalents.
3. Move shared field groups into dedicated schema classes immediately — do not let them grow inline.

Not every v3 component has a direct v4 unified equivalent yet; check the official changelog before assuming a component is context-aware.

Takeaways

• Filament v4's unified Schema API eliminates the form/infolist duplication that plagued v3 resources.
• A single schema() method serves both edit and view contexts via context injection.
• Extracting schemas into plain PHP classes (UserIdentitySchema::make()) is the cleanest reuse pattern.
• Conditional visibility with Get works uniformly across both contexts.
• Migrate incrementally: start with new resources, then refactor existing ones once you verify component parity.
