Filament v4 Schema-Based Forms, Infolists, and the Unified Schema API

Why the Old Approach Felt Redundant

In Filament v3, a typical resource forced you to define form() and infolist() separately. If your OrderResource displayed twelve fields, you wrote those fields twice — once as TextInput components, once as TextEntry components. The logic was identical; only the component class differed. Senior engineers reached for shared methods or traits to paper over the duplication, but it was always a workaround.

Filament v4 addresses this at the framework level with the unified Schema API.

The Unified Schema API in Practice

The core idea: a Schema is a context-aware tree of components. The same schema definition renders as an editable form inside CreateRecord or EditRecord, and as a read-only infolist inside ViewRecord. Components resolve their own rendering based on the active context.

use Filament\Schema\Schema;
use Filament\Schema\Components\TextInput;
use Filament\Schema\Components\Select;
use Filament\Schema\Components\Section;

public function schema(Schema $schema): Schema
{
    return $schema->components([
        Section::make('Customer')
            ->schema([
                TextInput::make('name')
                    ->required()
                    ->maxLength(255),

                Select::make('status')
                    ->options(OrderStatus::class)
                    ->required(),
            ]),
    ]);
}

You define schema() once on the resource. Filament resolves TextInput to an editable input on the form page and to a read-only text entry on the view page — no duplication, no trait gymnastics.

Opting Into Context-Specific Behaviour

Sometimes a field genuinely needs different behaviour per context. The API provides ->visibleOn() and ->hiddenOn() helpers, plus the lower-level ->when() callback that receives the active context string ('form', 'infolist'):

TextInput::make('internal_notes')
    ->hiddenOn('infolist'),

Select::make('assigned_to')
    ->options(fn () => User::pluck('name', 'id'))
    ->when(
        fn (string $context) => $context === 'form',
        fn (Select $field) => $field->searchable()->preload()
    ),

This keeps the single-schema principle intact while giving you an escape hatch.

Reusable Schema Fragments

Because a schema is just a PHP value, you can extract fragments into dedicated classes and compose them:

class AddressSchema
{
    public static function make(): array
    {
        return [
            TextInput::make('street')->required(),
            TextInput::make('city')->required(),
            TextInput::make('postcode')->required(),
        ];
    }
}

// Inside your resource:
Section::make('Shipping Address')
    ->schema(AddressSchema::make()),

This is the pattern that replaces the old getFormSchema() / getInfolistSchema() split. One fragment, used everywhere.

Table Columns Are Still Separate

It is worth being explicit: the unified Schema API covers forms and infolists only. Table column definitions remain in table() and have not been merged. This is intentional — table columns carry sorting, searching, and bulk-action concerns that do not map cleanly onto a field/entry duality.

Testing the New Schema

Pest assertions against Filament v4 schemas use the same livewire() helper, but the component class changes:

use function Pest\Livewire\livewire;

it('saves an order', function () {
    livewire(\App\Filament\Resources\OrderResource\Pages\CreateOrder::class)
        ->fillForm([
            'name' => 'Acme Corp',
            'status' => 'pending',
        ])
        ->call('create')
        ->assertHasNoFormErrors();
});

The assertion surface is unchanged; only the underlying schema resolution differs.

Key Takeaways

• One schema() method replaces separate form() and infolist() definitions on a resource.
• Components are context-aware — they render as inputs or entries depending on the active page.
• Use ->when() or ->hiddenOn() for the rare cases where context-specific behaviour is genuinely needed.
• Extract reusable fragments into plain PHP classes; they compose cleanly into any schema.
• Table columns remain separate — the unification is scoped to forms and infolists.
• Existing Pest assertions continue to work; no test-layer rewrite is required.
