Filament v4 Custom Field Plugins: Building Reusable Schema Components

Why Build a Filament v4 Field Plugin?

Filament v4 replaced the separate Forms\Components, Infolists\Components, and Tables\Columns hierarchies with a unified Schema API. Every renderable piece — form fields, infolist entries, table columns — now descends from Filament\Schemas\Components\Component. That single base class is your entry point when distributing a reusable field as a Composer package.

This article walks through building a ColourSwatchInput field that renders a native <input type="color"> with a hex-value label, packages it correctly, and wires up state hydration so Livewire round-trips work cleanly.

Scaffolding the Component Class

<?php

namespace Acme\FilamentColourSwatch\Schemas\Components;

use Filament\Schemas\Components\Field;

class ColourSwatchInput extends Field
{
    protected string $view = 'filament-colour-swatch::components.colour-swatch-input';

    protected bool $showHexLabel = true;

    public function showHexLabel(bool $show = true): static
    {
        $this->showHexLabel = $show;
        return $this;
    }

    public function getShowHexLabel(): bool
    {
        return $this->showHexLabel;
    }
}

Field already handles $statePath, $label, validation rules, and the Livewire entangle contract. You only add domain-specific configuration.

The Blade View

{{-- resources/views/components/colour-swatch-input.blade.php --}}
<x-filament-schemas::components.field :field="$field">
    <div class="flex items-center gap-3">
        <input
            type="color"
            id="{{ $field->getId() }}"
            {{ $applyStateBindingModifiers('wire:model') }}="{{ $field->getStatePath() }}"
            class="h-10 w-16 cursor-pointer rounded border border-gray-300"
        />
        @if ($field->getShowHexLabel())
            <span
                x-text="$wire.get('{{ $field->getStatePath() }}')"
                class="font-mono text-sm text-gray-600"
            ></span>
        @endif
    </div>
</x-filament-schemas::components.field>

$applyStateBindingModifiers is provided by Filament's view data and automatically appends .live, .lazy, or .debounce based on the field's configuration — never hardcode wire:model.live yourself.

Service Provider and Auto-Discovery

<?php

namespace Acme\FilamentColourSwatch;

use Filament\Support\Assets\Css;
use Filament\Support\Facades\FilamentAsset;
use Spatie\LaravelPackageTools\Package;
use Spatie\LaravelPackageTools\PackageServiceProvider;

class FilamentColourSwatchServiceProvider extends PackageServiceProvider
{
    public function configurePackage(Package $package): void
    {
        $package
            ->name('filament-colour-swatch')
            ->hasViews();
    }

    public function packageBooted(): void
    {
        FilamentAsset::register([
            Css::make('filament-colour-swatch', __DIR__ . '/../dist/colour-swatch.css'),
        ], 'acme/filament-colour-swatch');
    }
}

In composer.json, register the provider under extra.laravel.providers for zero-config auto-discovery:

{
  "extra": {
    "laravel": {
      "providers": [
        "Acme\\FilamentColourSwatch\\FilamentColourSwatchServiceProvider"
      ]
    }
  }
}

State Hydration and Default Values

Filament hydrates field state from the model or the form's fill() call. Because ColourSwatchInput extends Field, this is automatic. However, if you need a sensible default when the model attribute is null, override setUp:

protected function setUp(): void
{
    parent::setUp();

    $this->default('#000000');

    $this->rule('regex:/^#[0-9A-Fa-f]{6}$/');
}

Do not override getState() unless you need to transform the raw Livewire value — Filament's dehydration pipeline already handles casting through your model's Eloquent casts.

Using the Field in a Resource

use Acme\FilamentColourSwatch\Schemas\Components\ColourSwatchInput;

public static function form(Schema $schema): Schema
{
    return $schema->components([
        ColourSwatchInput::make('brand_colour')
            ->label('Brand Colour')
            ->showHexLabel()
            ->required(),
    ]);
}

Because the Schema API is unified, the same component class can appear in a form, an infolist (read-only via ->disabled()), or even a table filter — no duplication across namespaces.

Takeaways

• Extend Filament\Schemas\Components\Field — not the old v3 namespace — for full v4 compatibility.
• Use $applyStateBindingModifiers in Blade instead of hardcoding wire:model modifiers.
• Register assets via FilamentAsset::register() inside packageBooted(), not register().
• Auto-discovery via extra.laravel.providers means consumers need zero manual setup.
• Override setUp() for defaults and validation rules; avoid touching hydration internals unless truly necessary.
• The unified Schema API means one component class works across forms, infolists, and filters.
